3 - 66 USING THE COMBISCOPE INSTRUMENTS
3.12 Print/Plot Functions
The HCOPy:DEVice <TYPE> command allows you to select a hardcopy device.
The following selections can be made:
The HCOPy:DATA? query allows you to request a hardcopy of the picture on the
screen of your CombiScope instrument. The response data is formatted
according to the current printer/plotter options, which can be selected via the front
panel UTILITY menu. After a
*
RST command, the option "plotter; HPGL" is
selected.
The response data to a HCOPy:DATA? query can be sent to a connected plotter
or printer to make a hardcopy. The response data is sent as block data of
indefinite length and is therefore, preceded by the preamble #0 of 2 bytes. This
preamble must be removed from the beginning of the block data, before sending
it to a plotter or printer device.
DEVICE: TYPE: NOTE:
Plotter
Plotter
Plotter
Plotter
Plotter
Plotter
Plotter
Printer
Printer
Printer
Printer
Printer
Generator
HPGL
HP7440
HP7550
HP7475A
HP7470A
PM8277
PM8278
FX80
HP2225
LQ1500
HPLASER
HP540
DUMP_M1
HPGL plot data format
Epson FX80 compatibles (9 points)
ThinkJet
Epson LQ150 compatibles (24 points)
HP LaserJet series II & III
HP DeskJet (new style protocol)
Trace dump to one of the arbitrary waveform
generators PM5138, PM5139, or PM5150.
