CROSS REFERENCES B - 17
B.3 Cross Reference Functions / Commands
This section describes the SCPI commands that are related to the oscilloscope
functions and frontpanel keys. The oscilloscope functions and keys are described
in chapter 5 "Function Reference" of the Operating Guide. The SCPI commands
are specified in chapter 4 "COMMAND REFERENCE" of the SCPI Programming
Manual.
FUNCTION + KEYS/MENUS
RELATED SCPI COMMAND(S)
ACQUISITION LENGTH
key TB MODE
SYSTem:KEY 409
menu TB MODE
DISPlay:MENU TBMode
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
ACQ LENGTH
TRACe:POINts
-
trace length
FORMat[:DATA]
-
trace data
TRACe[:DATA]
-
trace copy
TRACe:COPY
ADD INVERT SUBTRACT
key CH1+CH2
SENSe:FUNCtion:... "XTIME:VOLTage:SUM 1,2"
key INV CH2
INPut2:POLarity
key CH3+CH4
SENSe:FUNCtion:... "XTIME:VOLTage:SUM 3,4"
key INV CH4
INPut4:POLarity
ADD (MATHEMATICS)
key MATH
SYSTem:KEY 111
menu MATH
DISPlay:MENU MATH
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
MATH1(2) ON/OFF
CALCulate[1|2]:MATH:STATe
-
add
CALCulate[1|2]:MATH[:EXPRession]
ALT/CHOP
key TB MODE
SYSTem:KEY 409
menu TB MODE
DISPlay:MENU TBMode
-
softkeys n = 1 .. 6
SYSTem:KEY n
ANALOG MODE
INSTrument:NSELect ANALog
INSTrument[:SELect] 2
key ANALOG
SYSTem:KEY 106
AUTO RANGE
key AUTO RANGE (MTB)
SENSe:SWEep:TIME:AUTO
key AUTO RANGE (CH1)
SENSe:VOLTage1[:DC]:RANGe:AUTO
key AUTO RANGE (CH2)
SENSe:VOLTage2[:DC]:RANGe:AUTO
key AUTO RANGE (CH3)
SENSe:VOLTage3[:DC]:RANGe:AUTO
key AUTO RANGE (CH4)
SENSe:VOLTage4[:DC]:RANGe:AUTO
