CROSS REFERENCES B - 25
FUNCTION + KEYS/MENUS
RELATED SCPI COMMAND(S)
TIMEBASE MODES
key TB MODE
SYSTem:KEY 409
menu TB MODE
DISPlay:MENU TBMode
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
AUTO
INITiate:CONTinuous ON
TRIGger:SOURce IMMediate
-
TRIG
INITiate:CONTinuous ON
TRIGger:SOURce INTernal<n>
-
SINGLE
INITiate[:IMMediate]
key SINGLE_ARM’D (indicator)
SYSTem:KEY 311
-
MULTI
none
-
ROLL
none
-
REAL-TIME ONLY
SENSe:SWEep:REALtime[:STATe]
TIME MEASUREMENTS
key MEASURE
SYSTem:KEY 110
menu MEASURE
DISPlay:MENU MEASure
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
MEAS 1 & MEAS 2
DISPlay:WINDow[1]:TEXT<1|2>:DATA?
-
frequency
MEASure:FREQuency?
-
period
MEASure:PERiod?
-
pulse width negative
MEASure:NWIDth?
-
pulse width positive
MEASure:PWIDth?
-
rise time
MEASure:RISE:TIME?
-
fall time
MEASure:FALL:TIME?
-
duty cycle negative
MEASure:NDUTycycle?
-
duty cycle positive
MEASure:PDUTycycle?
-
time of the first max value
MEASure:TMAXimum?
-
time of the first min value
MEASure:TMINimum?
Note:
MEASure? can be substituted by CONFigure + READ? or by CONFigure + INITiate +
FETCh?
TOUCH, HOLD & MEASURE
TM
key UTILITY
SYSTem:KEY 104
menu UTILITY PROBE
DISPlay:MENU UTIL
-
softkeys n = 1 .. 6
SYSTem:KEY n
Trace handling
-
trace length (number of points)
TRACe:POINts
-
trace point length
FORMat[:DATA]
-
trace data
TRACe[:DATA]
-
trace copy
TRACe:COPY
