B - 28 CROSS REFERENCES
FUNCTION + KEYS/MENUS
RELATED SCPI COMMAND(S)
VOLT MEASUREMENTS
key MEASURE
SYSTem:KEY 110
menu MEASURE
DISPlay:MENU MEASure
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
MEAS 1 & MEAS 2
DISPlay:WINDow[1]:TEXT<1|2>:DATA?
-
dc voltage
MEASure[:DC]?
-
rms voltage
MEASure:AC?
-
amplitude voltage
MEASure:AMPLitude?
-
max voltage
MEASure:MAXimum?
-
min voltage
MEASure:MINimum?
-
peak-to-peak voltage
MEASure:PTPeak?
-
high level voltage
MEASure:HIGH?
-
low level voltage
MEASure:LOW?
-
falling overshoot voltage
MEASure:FALL:OVERshoot?
-
falling preshoot voltage
MEASure:FALL:PREShoot?
-
rising overshoot voltage
MEASure:RISE:OVERshoot?
-
rising preshoot voltage
MEASure:RISE:PREShoot?
Note:
MEASure? can be substituted by CONFigure + READ? or by CONFigure + INITiate +
FETCh?
X-DEFLECTION (X-DEFL, X vs Y)
key DISPLAY
SYSTem:KEY 209
menu DISPLAY
DISPlay:MENU DISPlay
-
softkeys n = 1 .. 6
SYSTem:KEY n
Notes: The functions, keys, menus, and related SCPI commands for the
PM33x0B CombiScope instruments are:
- not applicable for channel 3.
- partly available for channel 4 as external trigger input.
