Running Individual Tests
Running a Single Test on Twisted Pair Cabling
4
4-5
Wall
outlet
PC
Transition
outlet
Patch cord
from hub
Patch cord
from PC
Horizontal
cross-connect
Horizontal
cabling
Telecommunications
closet
Work Area
Test Tool
Smart
Remote
TALK
Hub
Channel LIA
Channel LIA
oy08f.eps
Figure 4-1. Single Test Connections for Twisted Pair Cabling (Channel Connections Shown)
