Maintenance and Specifications
If the Test Tool Fails
8
8-5
Replacement Parts
Table 8-2 lists the replacement parts for the test tool and the remote. Other parts
may be available through a Fluke Networks service center. To order replacement
parts, contact Fluke Networks as described in Chapter 1.
Refer to the Fiber Test Adapters users manual for replacement parts for an optional
fiber test adapter.
Table 8-2. Replacement Parts
Description Part Number
NiMH battery pack 668225
AC adapter/charger, North America version 106200
AC adapter/charger, international version 944223
Battery door, main unit and remote, blue plastic 1992028
DSP-4000 Calibration Module 675611
Multimedia card reader, USB interface DSP-MCR-U
Cable, 50 Ω BNC coaxial, 1 m (3’) 927876
Cable, 9-pin PC interface 944806
Adapter, RJ45 to BNC 642402
Lens for main unit, DSP-4000 662590
Lens for main unit, DSP-4100 1575876
Lens for main unit, DSP-4300 1627114
Lens for remote, DSP-4000 662608
Lens for remote, DSP-4100 1575883
Lens for remote, DSP-4300 1627008
Bail, blue plastic 1992037
Strap 946769
Soft carrying case 669655
