Fluke DSP-4100 - Page 90

DSP-4000 Series
Users Manual
3-24
BNC “T”
Connector
12345678
PC
12345678
PC
12345678
PC
For Length Test,
remove far-end
Terminator
Test Tool
OFF
PRINT
MONITOR
SETUP
SPECIAL
FUNCTIONS
SINGLE
TEST
AUTO
TEST
DSP-4000
CABLE ANALYZER
TALK
EXIT
ENTER
TEST
SAVE
1
23
4
FAULT
INFO
Channel LIA
oy04f.eps
Figure 3-10. Autotest Connections for Coaxial Cabling
