2635A
Users Manual
4-4
RS-232
(DB-9)
(MALE)
COM PORT
(DB-9)
(MALE)
FLUKE R543 CABLE
(OR EQUAL)
PC CONNECTION
WITH DB-9
CONNECTOR
RS-232
(DB-9)
(MALE)
COM PORT
(DB-25)
(MALE)
FLUKE RS40 CABLE
(OR EQUAL)
PC CONNECTION
WITH DB-25
CONNECTOR
HYDRA
PC
HYDRA
PC
op48f.eps
Figure 4-1. Connecting the Instrument to a PC
