Fluke Hydra Series II User Manual

2635A
Users Manual
5-4
RS-232
(DB-9)
(MALE)
SERIAL-INPUT
PRINTER
RS-232
(DB-9)
(MALE)
COM PORT
(DB-25)
(RS40 MALE
OR RS42 FEMALE)
FLUKE RS40 OR RS42 CABLE
(OR EQUAL)
PARALLEL-INPUT
PRINTER
HYDRA
PRINTER
HYDRA
PRINTER
RS-232
(DB-25)
(RS40 MALE
OR RS42 FEMALE)
FLUKE RS40 OR RS42 CABLE
(OR EQUAL)
RS-232
DB-25
CONNECTOR
CENTRONICS-
TYPE
36-PIN
CONNECTOR
SERIAL-TO-PARALLEL
CONVERTER
op54f.eps
Figure 5-1. Connecting the Instrument to a Printer
