Fluke Hydra Series II User Manual

2635A
Users Manual
xviii
0:00:00
SET
INTVL
CANCL
Setting the Scan Interval. Press the INTVL key
to open the interval menu. Up/down and left/right
arrow keys select 0:00:00 (default) to 9:99:99.
The format is HOURS:MINUTES:SECONDS.
The scan interval is the total time between the
start of each measurement cycle. 0:00:00
represents continuous scanning. Press CANCL
to exit. [Figure 2-11]
C
D
REVIEW
SHIFT
REVIEW
CANCL
Selecting the Review Mode. Press the
REVIEW key to open the Review array. The
Review array holds the last, maximum, and
minimum readings during all previous scans for
all configured channels. Up/down arrow keys
select the channel, while left/right arrow keys
select LAST, MAX, and MIN. To CLEAR the
Review array, press the SHIFT key, release,
then press the REVIEW key. The Review array
is cleared automatically by changing any
parameter on any channel (including
Measurement Rate). Press CANCL to exit.
[Figure 2-18]
Select Channel 10. Select Channel 10 with the
up/down arrow keys. [Figure 2-3]
CH
20
...
10
...
0
REVIEW
0
10
LAST MIN MAX
op79_4f.eps
Ten Minute Tour (cont)
