Supported Network Standards
Table 4. Supported Network Standards
LAN Interfaces IEEE 10BASE-T, IEEE 100BASE-TX, IEEE
100BASE-F, IEEE 1000BASE-X
(RFCs: 1213, 1231, 1239, 1285, 1315, 1493, 1512,
1513, 1643, 1757, 2021, 2108, 2115, 2127, 2495,
2496, 2515, 2558)
IETF RFCs Supported 1493, 1512, 1513, 1643 (STD0050), 1748, 1749,
2011, 2012, 2013, 2021, 2108, 2115, 2819 (STD0059)
Cable Type Specification
Unshielded Twisted Pair LAN cables (100 and 120 Ohm UTP category 3, 4, 5, 5E,
and 6 ISO/IEC Class C and D)
Foil-screened Twisted Pair cables (100 and 120 Ohm ScTP category 3, 4, 5, and 6
ISO/IEC Class C and D)
Cable Length
Table 5. Cable Length, Resolution 0.1m (1 ft.)
Open or shorted 1 to 305m
(3 ft. to 1000 ft.)
+/- [2% of reading + 0.3 m (1 ft.)]
Terminated with
greater than or equal to
15% reflection
1 to 153m
(3 ft. to 500 ft.)
+/- [5% of reading + 0.3 m (1 ft.)]
Note
Length accuracy is dependent upon the cable type selected in the
Cable Test | Twisted-Pair Detail screen with its ideal NVP (nominal
velocity of propagation) matching the NVP of the cable under test.
Characteristic Impedance:
50 to 150 Ohms, cables 3-5 m (10-16 ft.) +/- (5 Ohms +10%)
50 to 150 Ohms, cables >5 m (16 ft.) +/- (5 Ohms +5%)
Resolution: 1 Ohm
