S IMPLIFIBER ENGLISH - 24
appropriate wavelength.
Note
When using a light source other than
SIMPLIFIBER Source, press the to select the
appropriate wavelength. Both units must be
set to the same wavelength.
6. Press, hold and release the button to
set and save the
new reference
value. The reference
value will be
displayed.
7. Disconnect the coupler without disturbing
the fiber connections to the units.
Measuring Loss using Method A
When Method A was used to set the reference,
proceed as follows:
1. Do not disconnect the launch cables from
the SIMPLIFIBER units.
2. Disconnect one launch cable from the
coupler.
3. Connect the fiber to be measured between
the launch cables. An extra coupler is needed.
4. SIMPLIFIBER Meter will report the loss in dB.
