FlyTech POS 360 Series - Page 47

40
COM3 & COM4 Power Setting
Function
JP3
(1-2) (3-4) (5-6) (7-8) (9-10) (11-12)
◎RI
+5V
COM3 Pin10
+12V
◎RI
+5V
COM4 Pin10
+12V
Cash Drawer Power Setting
Function
JP4
(1-2) (3-4) 5-6)
+12V
◎+19V
◎ = Default
1 3 5
246
1 3 5
246
1 3 5 7 9 11
24681012
1 3 5 7 9 11
24681012
1 3 5 7 9 11
24681012
1 3 5 7 9 11
24681012
1 3 5 7 9 11
24681012
1 3 5 7 9 11
24681012
