USER INSTTRUCTTIONS
IMPORTANT NNOTES
The installation of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter)
in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes
of Practice, the Building Regulations and the manufacturers’ instructions.
Failure to comply with the above recommendations could lead to prosecution and invalidate the appliance
warranty.
Please ensure you are handed all of the manufacturers documents on completion of the installation. This will
include these instructions.
Always keep a note of the installer’s name and address, the original purchase receipt and the date of installation
for future reference.
The fire and flue should be serviced regularly to ensure continued safe operation. See the servicing section for
further details. Frequency of service will depend on use, but MUST be carried out at least once annually.
Parts of this appliance become naturally hot during use. It is recommended that a suitable fire guard conforming
to BS 6778 is used, especially where young children, the elderly, or infirm are concerned.
The appliance requires a hearth with non-combustible surface of at least 12mm thick. The top surface must be at
least 50mm above the surrounding floor level, or be surrounded by a raised edge or fender 50mm high. The
hearth must protrude 325mm in front of the fireplace opening and extend at least 150mm on each side of the
incandescent area.
Combustible items, such as flooring and furniture, and soft wall coverings (such as blown vinyl or embossed
paper) may discolour if fitted too close to the fire. See relevant section for further details on clearances to
combustibles. No combustible material or flooring should protrude onto the hearth.
DO NOT burn any foreign material on this fire, the fuel effect must be of the correct type and laid out in accor-
dance with the relevant section of these instructions. Failure to do so could create a hazard or lead to sooting.
Before the appliance is installed, the chimney should be swept. All flues should be checked by the installer to
ensure there are no defects or obstructions that may prevent the flow of combustion products. This appliance is
fitted with a flue blockage safety device which will shut down the fire if abnormal flue conditions occur. It is NOT
a substitute for an independently mounted Carbon Monoxide detector. The fire is only suitable for use with the
gas type for which it is supplied.
CLEARANCES TTO CCOMBUSTIBLES
A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given
below.
1
Secction
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
Contentss
Important Notes
Clearances to Combustibles
Ventilation
Operating The Fire
Fuel Bed Layout
Flue Spillage Monitoring System
Cleaning
List of Spares
Pagge NNo.
1
2
2
2
3
3
3
4
Maximum ddepth oof sshelf MMinimum ddisstancce ffrom ffinisshed hhearth
ssurfacce tto uundersside oof sshelf
100mm (4in) 790mm (31 in)
150mm (6in) 890mm (35 in)
200mm (8in) 990mm (39 in)
1.0
2.0
