FUEL BED LAYOUT ((Glass/pebble mmodels) - ccontinued
2. Open the bag of 10 ceramic pebbles. All of these
pebbles are the same size, but may vary slightly in
shape in order to create a natural effect. Take six peb-
bles and place them as shown, in the centre of the burn-
er.
3. Take four more pebbles and place them as shown, on
top of the first six pebbles
The fire is designed to operate correctly with the pebbles supplied when assembled according to the instructions.
Never add to the ten pebbles, or change them for a different type. Never throw rubbish or other matter onto the
fuel bed.
Due to the light colour of the pebbles, some discolouration/sooting is to be expected during normal use.
FUEL BED LAYOUT ((Ceramat mmodels)
The Ceramat fuel bed is supplied ready for use, and no set up is required. The Mat itself is a high performance
burner medium of ceramic fibres which are welded together with silicon carbide in order to create a rigid mat
structure. The individual fibres of the mat can be seen to randomly illuminate when the appliance is used on lower
settings. The mat is fragile - if for any reason it is necessary to touch the mat, great care should be taken.
FLUE SSPILLAGE MMONITORING SSYSTEM
This fire is fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason
then several reasons may be suspected. If a door or window has been opened creating a draught, then pilot dis-
turbance could be the problem, and removal of the draught should resolve this. The fire can then be re-lit in accor-
dance with the previous section.
If pilot disturbance is not the cause, then the ODS safety system may be in operation. Switch the appliance OFF,
call in your installer to check the flue and ventilation and carry out any remedial work required. DO NOT allow
the appliance to be used until the flue system is passed as safe.
CLEANING
Before carrying out any of the following operations, ensure that the fire is OFF and completely cold. Debris that
may form on the firebed should be periodically removed by a competent person. Large deposits could indicate
deterioration of the flue. This should be repaired by a competent person, and the fire serviced before further use.
PAINTED AREAS - These can be cleaned using a dry cloth.
CERAMICS - See the relevant section in the Installation Guide of these instructions. Do not create dust from the
ceramics. Clean gently in the open air. Replace components with original spares only as necessary.
STAINLESS STEEL AREAS - These areas may be cleaned using a soft damp cloth or stainless steel cleaner.
IMPORTANT -
Always clean in the direction of the grain, and never across it as this will scratch the surface. It is
recommended that a small area is attempted before cleaning the entire stainless steel area - to ensure the clean-
ing material is suitable.
3
5.0
5.1
6.0
7.0
