Focusrite Clarett 4Pre USB User Manual

11
When mixing, you can connect an additional pair of speakers (mid-field, near-field, etc.) to
LINE OUTPUTS 3 and 4 to check your mix on different types of speaker. You can easily configure
Focusrite Control to route the mix to these outputs as well as Outputs 1 and 2.
Main
Monitor
Speakers
Additional
Monitor
Speakers
IMPORTANT:
LINE OUTPUTS 1 and 2 incorporate “anti-thump” circuitry that protects your speakers if
the Clarett 4Pre USB is turned on while the speakers (and amplifier if used) are connected
and active.
LINE OUTPUTS 3 and 4 do not have this circuitry.
If you’re using additional speakers connected to these outputs, we recommend that you
power your Clarett 4Pre USB on first, then turn on the speakers or power amplifier. But
get into the habit of following the general rule in any case - it is always good audio practice
to turn on a speaker system of any kind after turning on the equipment feeding it.

Focusrite Clarett 4Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)	0.001 %
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
USB port type	USB Type-C
USB ports quantity	1
6.35 mm (1⁄4-inch) input	4
6.35 mm (1⁄4-inch) output	6
DC output voltage	12 V

Weight and Dimensions

Depth	192 mm
Width	222 mm
Height	63.5 mm
Weight	1350 g
