Focusrite Clarett 4Pre USB User Manual

19
Line & Monitor Outputs
Dynamic Range 118 dB
THD+N 0.0006%
Maximum Output Level (0 dBFS) +18 dBu, balanced line/TRS outputs
Headphone Outputs
Dynamic Range 115 dB (A-Weighted)
THD+N 0.0003% > 100R
Maximum Output Level +15 dBu > 100R
Physical and Electrical Characteristics
Analogue Inputs 1 to 4
Connectors
Combo XLR sockets: Mic/Line/Inst (Inputs 1 & 2); Mic/Line
(Inputs 3 & 4) on front panel
Mic/Line switching Automatic
Line/Instrument switching
(Inputs 1 & 2)
via Focusrite Control
Phantom power +48 V switches for inputs 1 & 2, 3 & 4
Analogue Inputs 5 to 8
Connectors 4 x balanced ¼” TRS jacks, on rear panel
Analogue Outputs
Main outputs 4 x balanced ¼” TRS jacks, on rear panel
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
ADAT Input
TOSLINK optical connector:
8 channels at 44.1/48 kHz
4 channels at 88.2/96 kHz
Optical S/PDIF input (selectable)
S/PDIF I/O 2 x RCA
Data connector (to computer) 1 x USB-C™ connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H 222 mm x 192 mm x 63.5 mm / 8.74” x 7.56” x 2.5”
Weight
1.35 kg
2.98 lbs

Focusrite Clarett 4Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)	0.001 %
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
USB port type	USB Type-C
USB ports quantity	1
6.35 mm (1⁄4-inch) input	4
6.35 mm (1⁄4-inch) output	6
DC output voltage	12 V

Weight and Dimensions

Depth	192 mm
Width	222 mm
Height	63.5 mm
Weight	1350 g
