Focusrite Clarett 4Pre USB User Manual

18
CLARETT 4PRE USB TECHNICAL SPECIFICATIONS
Performance Specifications
Configuration
Inputs 18: analogue (8), S/PDIF (2), ADAT (8)
Outputs 8: analogue (4), S/PDIF (2), HP (2)
Mixer Fully assignable 26-in/10-out mixer
Digital Performance
Supported sample rates 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz & 192 kHz
Microphone Inputs
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 118 dB
THD+N 0.0009%
Noise EIN <–128 dB (A-weighted)
Maximum input level +18 dBu at minimum gain
Gain Range 57 dB
Line Inputs 1-4 (Variable Gain)
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 118 dB
THD+N 0.001%
Maximum input level +26 dBu at minimum gain
Gain Range 57 dB
Line Inputs 5-8 (Fixed Gain)
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 118 dB
THD+N 0.001%
Maximum input level +18 dBu at minimum gain
Gain Range 57 dB
Instrument Inputs
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 117 dB
THD+N 0.001%
Maximum input level +14 dBu at minimum gain
Gain Range 57 dB

Focusrite Clarett 4Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)	0.001 %
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
USB port type	USB Type-C
USB ports quantity	1
6.35 mm (1⁄4-inch) input	4
6.35 mm (1⁄4-inch) output	6
DC output voltage	12 V

Weight and Dimensions

Depth	192 mm
Width	222 mm
Height	63.5 mm
Weight	1350 g
