Focusrite Forte - Appendix; Factory Default Settings; Performance Specifications

24
Appendix
Forte Control – Factory default settings
Input channels 1 & 2
Source Line
Gain 0 dB
48 V Off
HPF Off
Pad Off
Phase Normal
Stereo link Off
Output channels – main and headphones
Level -30 dB
Dim Off
Mute Unmuted
Mono Off
Digital Monitor Mixer – Speaker Mix and Headphone Mix
Inputs 1 & 2 levels 0 dB
DAW 1 - 4 levels 0 dB
Panning Centre
Mutes Unmuted
Solos Off
Stereo link Inputs – Off; DAW 1 & 2 and DAW 3 & 4 - On
Performance Specifications
Real World ADC Dynamic Range 117 dB (A-weighted)
Real World DAC Dynamic Range 118 dB (A-weighted)
Chipset ADC/DAC DNR 120 dB (A-weighted)
Microphone Inputs
Type
RedNet remote controlled pre-amplifier; electronically balanced,
Z
in
~1.3k ohms
Gain Range 0 to +75 dB
