Focusrite Forte - Physical And Electrical Characteristics; Troubleshooting

26
THD + N @ -1 dBFS <0.0008% (@ 1 kHz, 20 Hz – 22 kHz, 10k ohms load)
Maximum Output into 10 k ohms +9 dBu (+7 dBV)*
Maximum Power into 150 ohms 30 mW
Maximum Power into 32 ohms 27 mW
Output Impedance <8 ohms
Suitable load Impedance >32 ohms
Crosstalk
Input to Input >-90 dB
Output to Output >-90 dB
Input to Output >-90 dB
Additional DSP performance
Clock jitter <250 ps
Supported sample rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
*NOTE - with 5V DC external power supply
Physical and Electrical Characteristics
Analogue Inputs
Connectors 2 x XLR3F (mic); 2 x TRS ¼” jack (line/inst)
Mic/Line/Inst switching via software
Analogue Outputs
Main outputs 2 x ¼” TRS jacks; electronically balanced
Headphone outputs 1 x ¼” TRS jack; stereo headphone
Other I/O
USB 1 x USB 2.0 Type B connector
Ext DC in 5 V @ 1 A (via supplied PSU only)
Weight and Dimensions
W x H x D 115 x 345 x 171 mm (without connectors)
Weight Approx 487 g
Troubleshooting
For all troubleshooting queries, please visit the Focusrite Answerbase at
http://www.focusrite.com/answerbase where you will find articles covering numerous trouble-
shooting examples.
