PERFORMANCE AND SPECIFICATIONS
Microphone Inputs
Gain Range 0-8 to 63 dB in 1dB steps
Maximum Input Level >+19dBu
Input Impedance 6.2 kΩ, electronically balanced | Air Mode: 2.2 kΩ
Dynamic Range 119 dB ‘A’-Weighted (typical), minimum gain
Frequency Response 20 Hz – 35 kHz ±0.2dB | Air Mode: 2dB boost at 10 kHz and -2 dB at 20 kHz (ref. 1 kHz)
THD + N -101dB (0.0009%) @ -1 dBFS
HPF -3 dB @ 80 Hz, 12 dB/octave
EIN <-129 dBu ‘A’-Weighted (typical)
Line Inputs 1 –16
Maximum Input Level +18 or +24 dBu 0 dBFS switchable per channel
Dynamic Range 119 dB ‘A’-Weighted
Frequency Response 20 Hz – 35 kHz ±0.2 dB | Air Mode: 2dB boost at 10 kHz and -2 dB at 20 kHz (ref. 1 kHz)
THD + N -102dB (0.0008%) @ -1 dBFS
HPF -3 dB @ 80 Hz, 12 dB/octave Channels 1 & 2 only
CMRR -70 dB 50/60 Hz
Instrument Inputs
Gain Range 0-8 to 63 dB in 1dB steps
Maximum Input Level >+15dBu
Input Impedance 2.3 MΩ
Dynamic Range 117 dB ‘A’-Weighted
Frequency Response 20 Hz – 35 kHz ±0.2 dB | Air Mode: 2dB boost at 10 kHz and -2 dB at 20 kHz (ref. 1 kHz)
THD + N -100dB (0.001%) @ -1 dBFS
HPF -3 dB @ 80 Hz, 12 dB/octave
Line Outputs 1 – 16
Maximum Output Level +18 or +24 dBu 0 dBFS switchable per channel
Dynamic Range 121 dB ‘A’-Weighted
Frequency Response 20 Hz – 35 kHz ±0.3 dB
THD + N <-104dB (0.0006%) @ -1 dBFS
