Input/Output Interface
Video Interfaces
HDMI
、
SDI
、
LAN(POE)
、
USB2.0
、
A-IN
、
RS232-IN
、
RS232-OUT
、
RS422(compatible
with RS485)、DC12V Power Supply、Rotary Dip Switch、Power Switch
Video Output
HDMI, SDI, LAN,USB2.0
Video Stream
Dual stream output
Video Format
Main Stream: 1920×1080, 1280×720, 640×480
Sub Stream: 1280×720, 640×480, 640×360, 320×240, 320×180
Video Bitrate
64Kbps～40960Kbps
Video Compression
Format
LAN
：
H.264
、
H.265
USB 2.0：MJPG、H264、H.265、YUY2、NV12
Audio Input Interface
Double track 3.5mm linear input
Audio Output
Interface
HDMI, SDI, LAN
Audio Compression
Format
AAC/MP3/G.711A
Audio Bitrate
32Kbps, 48Kbps, 64Kbps, 96Kbps, 128Kbps
Network Interface
100M Ethernet port（10/100BASE-TX）
Control Interface
RS232 (IN/OUT), RS485, RS422
Control Protocol
VISCA/Pelco-D/Pelco-P, Baud Rate: 115200/38400/9600/4800/2400bps
Power Interface
HEC3800 outlet (DC12V)
Power Supply
Input AC110V-AC220V; Output DC12V/2.0A
Input Voltage
DC12V±10%
Input Current
Maximum: 1A
Power Consumption
Maximum: 12W
Network Protocols
TCP/IP, RTSP, RTMP, VISCA OVER IP, IP VISCA, RTMPS, SRT, NDI, ONVIF, GB/T28181;
Support Network VISCA control protocol；
Support remote upgrade, reboot and reset
PTZ Parameter
Pan/Tilt Rotation
±170°, -30°～+90°
Pan Control Speed
1.4 - 40°/sec
Tilt Control Speed
2.9 - 30°/sec
Preset Speed
Pan: 40°/sec, Tilt: 30°/sec
Preset Accuracy
±0.1°
Preset Number
255 presets (10 presets via remote control)
Other Parameter
Stored Temperature
-10℃~+60℃
Stored Humidity
20%~95%
Working
Temperature
-10℃~+50℃
Working Humidity
20%~80%
Dimension
143mm×176mm×169mm
Weight
1.2KG
Accessory
Package
Power Supply, RS232 Control Cable, IR Remote Control, User Manual
Optional Accessories
Ceiling / wall Mount (Extra Cost)
