FoMaKo -
Focus Your Streaming www.fomako.net
15
Unified Communication, Emergency command and control systems, etc.
Multiple Video Output Interfaces: HDMI, SDI, LANUSB2.0; Simultaneously output audio and video
signal via HDMI, SDI and LAN; SDI output could up to 100M with 1080P@60fps
Multiple Audio/Video Compression Standards: Support H.264/H.265 video compression, up to 1920×1080
resolution 60fps; support AAC, MP3 and G.711A audio compression, 16000, 32000, 44100, 48000 sampling
frequency
Built-in Gravity Sensor: Support PTZ auto-flip function and easy installation.
Multiple Network Protocol: Support ONVIF, GB28181, RTSP, RTMP,VISCA OVER IP, IP VISCA,
RTMPS, SRT, NDI protocols; Support RTMP push mode, easy to be connected to streaming server (Wowza,
FMS); Support RTP multicast mode; Support network full command VISCA control protocol.
Control Interface: RS422, RS485, RS232 (cascade connection)
Multiple Control Protocol: Support VISCA, PELCO-D, PELCO-P protocols; Support automatic identification
protocols.
Quiet Pan / Tilt Movement: With high accuracy step driving motor, camera can pan / tilt extremely quiet and
smooth.
Sleep function with low power: Support sleep/wake up function with low power consumption, less than
400mw.
Multiple Presets: Up to 255 presets (10 presets via remote control).
IR Remote Control: Users can use IR remote control to control the camera, can also do menu settings by
HDMI and SDI Connection to display device.(LAN connection can't use menu setting by IR Remote Contol)
OLED display: It can display the states and parameters of the camera and convenient for the user to view
and adjust, can check the IP address of the camera, real-time information display such as resolution, frame
rate, easy to monitor and control
Multiple Application: Online-education, Lecture Capture, Webcasting, Video conferencing, Tele-medicine,
2.6
Technical Parameter
Model
12X
20X
30X
Camera Parameter
Optical Zoom
12X
f4.1-49.2mm
20X
f5.1-94.5mm
30X
f5.2-148.4 mm
Sensor
1/2.8 inch high quality HD CMOS sensor
Effective Pixels
16: 9, 2.07 megapixel
Video Format
HDMI/SDI
1080P601080P501080P301080P25720P60720P501080P59.941080P29.97
720P59.94
USB2.0:
H264/H265/MJPEG:
320x240/352x288/640x360/640x480/704x576/704x480/720x576/800x448/800x600/960x540/
1024x576/1024x768/1280x720/1920x1080P30/25/20/15/10/5
YUY2: 320x240/640x360/640x480P30/25/20/15/10/5
NV12: 640x360/640x480P30/25/20/15/10/5
View Angle
6.6°
N
70.3°
W
3.5°
N
60°
W
2.14°T58.1°W
AV
F1.8 F2.68
F1.8 F2.9
F1.3 F4.8
Digital Zoom
10X
Minimum
Illumination
0.5 Lux (F1.8, AGC ON)
DNR
2D & 3D DNR
White Balance
Auto/Manual/One-push/3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
Focus Mode
Auto/Manual/One Push Focus
Exposure Mode
Auto/Manual/Shutter Priority, Aperture Priority, Brightness Priority
Iris
Auto/Manual
Electronic Shutter
Auto/Manual
BLC
ON/OFF
WDR
OFF/ Dynamic level adjustment
Video Adjustment
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR
>55 dB
