EDITION MODE
MPX-4088
The edition mode of the MPX-4088 allows real-time editing of input/output signal processing parameters,
allocation of sources to zones, attenuation of signal level inputs, feedback cancellation, auto-mix, presets to
b
e saved and loaded, relays to be activated/deactivated, the device name to be changed and factory values
to be restored. By default, the Input DSP Channel tab is displayed.
INPUT DSP CHANNEL
2.- EXP/GATE MODULE:
Add dynamic to the signal for each input channel. When the input signal is below the
threshold, the expander amplifies it with the ratio value adjusted. If the signal is above
the threshold, the output remains identical. By adjusting the ratio value to the maximum
(Limit), the expander becomes a noise gate.
a.- Graphic display of EXP/GATE module.
b.- Release: expander release time when the signal goes above the threshold.
c.- Ratio: amplification ratio between input signal and amplified signal.
d.- Threshold: threshold value, the signal below this value will be amplified according to the selected
amplification ratio.
e.- Attack: expander reaction time when the input signal is below the threshold value.
f.- Bypass: the input signal is not processed and is diverted to the next processing module.
g.- Default: resets the default values of the EXP/GATE module.
