FONESTAR MPX-4088 - MPX-420 V AND MPX-430 VS CONTROLS; Front Panel Controls

MPX-420V AND MPX-430VS
DESCRIPTION
The models MPX-420V and MPX-430VS are remote volume and zone controls for the matrix mod.
MPX-4088. The model MPX-430VS incorporates two euroblock balanced audio outputs.
CONTROLS AND FUNCTIONS
FRONT PANEL
1.- LCD DISPLAY: displays information about volume in each zone and allocation of inputs to zones.
2.- VOL./ : volume control and zone allocation.
INTERIOR PANEL MPX-420V
1.- RD port for connection to MPX-4088 matrix. RJ-45 connector.
2.- RD LINK port for connection in series of remote controls MPX-420V.
- 22 -
