Ford FUSION Owner's Handbook

Driving with a trailer
E71331
A
B
WARNING
If any of the below conditions
cannot be met, do not use the
tow bar and have it inspected by an
expert.
Before starting your journey, ensure
the tow ball arm is properly locked.
Check that:
•
the green marks are aligned
•
the handwheel (A) is correctly
fitted to the tow ball arm.
•
you have removed the key (B).
•
the tow ball arm is securely
positioned. It must not move
when jerked.
Removing the tow ball arm
3
1
E71332
2
Note: Unhitch the trailer.
1. Remove the protecting cap. Press
the cap into the key bow. Insert
the key and unlock.
2. Hold the tow ball arm. Pull the
handwheel out and turn it
clockwise against the stop.
3. Remove the tow ball arm.
4. Release the handwheel.
When unlocked in this way, the tow
ball arm can be reinserted at any
time.
101
Towing
