12
Parameter Unit
Product control Interactive touchscreen, manual control pedals for manual
media blast and air rinse control
Included Accessories Transfer container
Control pedals
ESD wrist strap
7 mm socket wrench
3 mm blast orifice
4 mm blast orifice (installed)
T20 Torx driver
Floor mat
Alerts Touchscreen alerts
2.3 Product components
2.3.1 Fuse Blast – Front
Door latch: Secures the blasting chamber.
Blasting chamber door: A tempered glass
window prevents powder and debris from
leaving the Fuse Blast’s workspace and
provides access to the tumbler basket and
blast gun.
Blast lights: Provides light to the Fuse
Blast’s workspace.
Tumbler basket: Rotates to agitate parts and
ensure even coverage during automated
media blasting.
Blast gun: Blasts printed parts with media
and then cleans them with forced ionized air.
Blast arm: Holds blast gun in position for
assisted manual blasting or an automatic
blasting cycle.
Touchscreen: The LCD capacitive touch
user interface displays cleaning cycle information, settings, and error messages.
Blast gloves: Allows users to manipulate and clean items while the Fuse Blast chamber
doors are secured.
HEPA filter door: Sealed and interlocked door for accessing the HEPA air filter.
Media hopper window: Allows for visual check of powder level in the hopper.
Waste hopper window: Allows for visual check of waste level in the hopper.
Foot pedals: Manual controls for the air rinse and media blasting.
Media hopper valve: A knife valve used to close o and open the valve to empty the
media hopper.
Work surface: A grated surface in the interior of the blasting chamber that also allows media
and powder to drain into the chamber chute. Place parts here during manual blasting.
Grounding strap plug: A plug for attaching the included anti-static wrist strap used to protect
users and electronics from static electricity build up. Recommended for manual mode.
1
2
3
4
5
6
7
8
9
10
1 1
12
13
14
15
