NT8 User's Guide | Chapter 6: Initial Setup
Installing the LV Tip Caddy
1. Place the LV tip caddy on the LV tip caddy station.
2. Make sure it is secure.
Installing the Reference Plate
1. Put the reference plate on the desired microplate station.
2. Make sure the arrow mark position is on the top-
right corner.
Installing the HV Tip Caddy
1. Click the button to move the NT8's head to the left and stage
back. This will allow you to slide the HV tip caddy into place.
2. Slide the tip caddy into position.
H
