Fortinet FortiGate FortiGate-100 Administration Guide

System config Fortinet MIB fields
FortiGate-100 Administration Guide 01-28006-0003-20041105 105
Table 16: Administrator accounts
MIB field Description
index The index number of the administrator account added to the FortiGate unit.
name The user name of an administrator account added to the FortiGate unit.
addr Up to three trusted host IP addresses for the administrator account.
mask Up to three trusted host netmasks for the administrator account.
perm The access profile assigned to the account.
Table 17: Local users
MIB field Description
index The index number of the local user added to the FortiGate unit.
name The user name of the local user added to the FortiGate unit.
auth The authentication type of for the local user. Can be password, LDAP, or
RADIUS.
state Whether the local user is enabled or disable.
Table 18: Virtual domains
MIB field Description
index The index number virtual domain added to the FortiGate unit.
name The name of the virtual domain added to the FortiGate unit. Each FortiGate
unit includes at least one virtual domain named root.
auth The authentication type of for the local user. Can be password, LDAP, or
RADIUS.
state Whether the local user is enabled or disable.
Table 19: Active IP sessions
MIB field Description
index The index number of the active IP session.
proto The IP protocol (TCP, UDP, ICMP, and so on) of the IP session.
fromAddr The source IP address of the active IP session.
fromPort The source port of the active IP session.
toPort The destination IP address of the active IP session.
toAddr The destination port of the active IP session.
expiry The expiry time or time-to-live in seconds for the session.

Fortinet FortiGate FortiGate-100 Specifications

General

Brand	Fortinet
Model	FortiGate FortiGate-100
Category	Firewall
Language	English
