Fortinet FortiGate FortiGate-100 Administration Guide

98 01-28006-0003-20041105 Fortinet Inc.
Configuring SNMP System config
RFC support includes support for most of RFC 2665 (Ethernet-like MIB) and most of
RFC 1213 (MIB II) (for more information, see “FortiGate MIBs” on page 101).
This section describes:
• Configuring SNMP
• SNMP community
• FortiGate MIBs
• FortiGate traps
• Fortinet MIB fields
Configuring SNMP
Go to System > Config > SNMP v1/v2c to configure the SNMP agent.
Figure 33: Configuring SNMP
SNMP Agent Enable the FortiGate SNMP agent.
Description Enter descriptive information about the FortiGate unit. The description
can be up to 35 characters long.
Location Enter the physical location of the FortiGate unit. The system location
description can be up to 35 characters long.
Contact Enter the contact information for the person responsible for this FortiGate
unit. The contact information can be up to 35 characters long.
Apply Save changes made to the description, location, and contact information.
Create New Select Create New to add a new SNMP community.
Communities The list of SNMP communities added to the FortiGate configuration. You
can add up to 3 communities.
Name The name of the SNMP community.
Queries The status of SNMP queries for each SNMP community. The query
status can be enabled or disabled.
Traps The status of SNMP traps for each SNMP community. The trap status
can be enabled or disabled.
Enable Select Enable to activate an SNMP community.
Delete icon Select Delete to remove an SNMP community.
Edit/View icon View or modify an SNMP community.
