Fortinet FortiGate FortiGate-800

Firewall Service
FortiGate-800 Administration Guide 01-28006-0008-20041105 211
ICMP custom service options
Figure 91: ICMP custom service options
IP custom service options
Figure 92: IP custom service options
Configuring custom services
To add a custom TCP or UDP service
1 Go to Firewall > Service > Custom.
2 Select Create New.
3 Enter a name for the new custom TCP or UDP service.
4 Select TCP or UDP as the Protocol Type.
Source Port Specify the Source Port number range for the service by entering the low
and high port numbers. If the service uses one port number, enter this
number in both the low and high fields.
Destination Port Specify the Destination Port number range for the service by entering the
low and high port numbers. If the service uses one port number, enter this
number in both the low and high fields.
Name The name of the ICMP custom service.
Protocol Type Select the protocol type of the service you are adding (ICMP).
Type Enter the ICMP type number for the service.
Code Enter the ICMP code number for the service if required.
Name The name of the IP custom service.
Protocol Type Select the protocol type of the service you are adding: IP.
Protocol Number The IP protocol number for the service.
