fos4X fos4Strain expert - Technical Specifications

3. Product Description
3.2 Technical Data
3.2.1 Measurement and Optical Data
For technical data on the measurement and optical properties, see the sensor data
sheet.
Data sheets available at www.fos4x.de/en/downloads.
3.2.2 Cable Data
Table 3: Cable Data
Property Value Unit
Length
*
See type plate -
Diameter (cable with step protection) 6 ± 0.5 mm
Min. Bending radius (cable with step
protection)
50 mm
Min. bending radius (fan-out cable) 15 mm
Cable exchangeable No -
Connector type E-2000/APC -
* Length from sensor end to connector end.
3.2.3 Environmental Conditions
Table 4: Environmental Conditions
Property Value Unit
IP protection class
*
IP67 -
Maximum operating altitude 3000 m
Permitted temperature
(Transport and storage)
-40 … +80 °C
Permitted relative humidity
(Transport and storage)
0 … 95 %
Permitted temperature
(Operation)
-40 … +55 °C
14 / 42 4-10_1.3.x_4.0_fos4Strain expert-en-us © fos4X 2019
