5. Installation
5.3.2 Attaching the Sensor with UHU PLUS BLACK
CAUTION
Burns caused by touching hot surfaces.
u
Do not touch hot surfaces.
u
Allow hot surfaces to cool down after work.
u
Wear protective gloves (protection against contact heat
performance level 2 according to DIN EN 407).
NOTICE
Incorrect or inaccurate measurements due to incorrect
installation.
After curing, the sensor is permanently bonded to the
substrate and cannot be removed.
u
Ensure that the sensor is installed at the correct position.
u
Ensure that enough adhesive is applied.
u
Use the original Mixing Tip short / 77mm (UH46775) for
the adhesive UHU PLUS BLACK.
TIP
fos4X recommends: Use the Application Tool for curing the
adhesive. See instructions for use of the Application Tool.
Material and equipment
Table 13: Material and equipment
Name Type Quantity
Mixing gun UH46770 1
Mixing Tip short /
77mm
UH46775 1
Adhesive tape Kapton As required
MEC1294 Application Tool RD 230 V 1
Optional:
Application Tool
MEC1295 Application Tool RD 110 V 1
Optional:
Measuring Case
MSY0961 Measuring Case (dyn4) 1
© fos4X 2019 4-10_1.3.x_4.0_fos4Strain expert-en-us 27 / 42
