5. Installation
5.3 Attaching the Sensor
5.3.1 Attaching the Sensor with ergo 1665
NOTICE
Incorrect or inaccurate measurements due to incorrect
installation.
After curing, the sensor is permanently bonded to the
substrate and cannot be removed.
u
Ensure that the sensor is installed at the correct position.
u
Ensure that enough adhesive is applied.
u
Use the helix-mixer B-System / 4:1 & 10:1 / 50ml for the
adhesive ergo. 1665.
Material and equipment
Table 11: Material and equipment
Name Type Quantity
Mixer
4472043
Helix-mixer, B-System / 4:1 & 10:1 /
50ml
1
Mixing gun
4472105
Manual mixing gun / 10:1 / 50ml
1
Caulking gun - 1
Adhesive tape Kapton As required
Optional:
Measuring Case
MSY0961 Measuring Case (dyn4) 1
Consumables
Table 12: Consumables
Name Type Quantity
Adhesive
ergo 1665®
1665.050.DK.E500
As required
Adhesive ergo.® 6305 or Sikaflex-521UV As required
Cleaning agent Isopropanol As required
© fos4X 2019 4-10_1.3.x_4.0_fos4Strain expert-en-us 23 / 42
