NVR User Manual
www.foscam.com
2
GUI
Please refer to the Quick Setup Guide if you install the NVR for the first time. You can visit
the local NVR device via the display or monitor, and view or manage NVR system.
2.1 Before Starting
You need to know some basic information before you log on to the NVR system with the monitor or
display.
2.1.1 Icons Description
In the live view mode, there are icons at the left top of the full screen.
: The HDD is full, and the recording has been stopped. A HDD is not inserted into the NVR or
the HDD connected to the NVR is abnormal.
In the live view mode, there are icons at the right bottom of the screen for each channel,
: Human Detection Alarm. Identify whether someone is moving within the range of the camera.
Only FN7108W-B4 kit supports this function.
: Motion Detection Alarm. The motion is detected during the detection time in the detection
area, the NVR will alarm.
: NVR is recording for the IPC.
: You can click this icon to control whether IPC records sound.
: Shows the strength of the IPC wireless network.Only FN7108W-B4 kit supports this function.
2.1.2 Common Operations
Starting Up the NVR
Turn on the power, The Power indicator LED should turn green indicating that the device begins to
start up.
