NVR User Manual
www.foscam.com
6
Note
If the power LED indicator on the front panel is off, please check if the power supply is plugged into
an electrical outlet.
Shutting Down the NVR
Proper ways to shut down the NVR in the GUI interface: After login, right-click the mouse, you can
click Shutdown in the shortcut menu. Choose Shutdown, click the OK button in the confirmation
box. Then turn off the power switch on the rear panel, the power LED indicator on the front panel
turns off.
Note
Don't turn off the power directly when you turning on.
Reset
You can reset the NVR device to restore the factory settings. You can choose any one of the
following methods operate.
 Reset button: Press and hold it for 3 seconds to reset all parameters to factory defaults on the
bottom of the NVR.
 Local GUI: Right-click the mouse, Choose Main Menu > Restore in the Menu interface, then
choose to restore defaults in the Restore factory settings interface.
2.1.3 USB Mouse Operation
Plug USB mouse into one of the USB interfaces on the rear panel of the NVR.
The operation of the mouse on the local GUI is shown as below.
Name
Action
Description
Left-Click
Single-Click
Menu or window: select and enter.
Double-Click
Preview mode or Playback mode: Switch between single-screen
and multi-screen.
Click and Drag
Time or Area box: Select the time or zone range.
Time bar: Drag time bar.
