Foscam R2 User Manual

3
Front panel:
 LENS: Fixed focus lens.
 Infrared LED: Infrared LEDs for night vision.
 Microphone: Built-in microphone.
 Micro SD Card slot: Supports up to 64GB SD card for storing the video.
 WPS/Reset
 WPS: Push both WPS/Reset button on the camera and wireless router within 1 minute, the
camera will connect to the wireless router automatically, in WPS process, the Network light will
blink every 0.4 seconds;
 Reset: Push and hold the WPS/Reset button for more than 10 seconds to set the camera to
factory default, the Power light will blink every 0.4 seconds;
Rear panel:
 LAN: 10/100 Mbps RJ-45 port for wired connection
 Power: DC 5V/2A Power supply.
 Speaker: Built-in speaker
 Antenna: Used to connect external wireless antenna
The flashing status of the Power light and Network light are shown in the following table.
Light
Flashing Status
Description
Power light
off
The power don't work properly.
on
The power supply works fine.
Flashing every 0.4 seconds
Reset to take effect
Network light
off
No Wireless connection
Constant Flash
Wired connection
Slow Flash every 1.0 second
Wi-Fi connected
Flashing every 0.4 seconds
WPS is connecting
Flashing every 0.2 seconds
EZLink takes effect
1.5 Micro-SD Card
This camera supports SD Card.
When you plug in the SD card during the camera work process, please reboot the camera again, or else
the SD Card may be cannot work well.
Go to the SettingsDevice StatusDevice Status page, you can see the SD card status.

Foscam R2 Specifications

General

Type	IP security camera
PTZ control	Yes
Antenna type	External
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Cube
Mounting type	Desk
Product color	White
Full HD	No
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Night vision distance	8 m
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Interface	RJ-45
Power over Ethernet (PoE)	-
Power consumption (typical)	4.8 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	70 mm
Height	120 mm
