Page #113 background imageLoading...
Page #113 background image
111
More FAQs are available here:
https://www.foscam.com/faqs/index.html
5.2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
Username and password
Default admin username: admin with a random password
5.3 Specification
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
2.0MegaPixels
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
Focal Length
f: 5.4mm-97.2mm
Aperture
F1.7~F3.6
Angle of View
Horizontal: 3.55°~55.4° Diagonal : :4.05°~62.6°
Video
Image Compression
H.264
Image Frame Rate
25fps1080P/15fps720P/, downward adjustable
Resolution
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip Image
flip and mirror
Infrared Mode
Automatic and manual
IR Range
6pcs Infrared-LEDs, night vision range up to 50 metres
Audio
Input/Output
Supports two-way audio
Audio Compression
PCM/G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Remote Access
P2P
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.).
Wireless Standard
2.4G/5G dual band, IEEE802.11b/g/n/ac
Network Protocol
IPTCPUDPHTTPHTTPSSMTPFTPDHCP
RTSPONVIF

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Foscam SD2X and is the answer not in the manual?

Foscam SD2X Specifications

General IconGeneral
Form factorDome
Mounting typeWall
Product colorWhite
International Protection (IP) codeIP66
Camera pan control-
Minimum illumination0 lx
Optical zoom18 x
Zoom capabilityYes
Number of lenses1
Focal length range5.4 - 97.2 mm
Maximum aperture number3.6
Minimum aperture number1.7
LED typeIR
Night vision distance50 m
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Supported video modes240p, 480p, 720p, 1080p
Video formats supportedH.264
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)450 Mbit/s
Ethernet interface typeFast Ethernet
Supported network protocolsIP, TCP, UDP, HTTP, HTTPS, DHCP, SMTP, FTP, RTSP, ONVIF
TypeIP security camera
Antenna typeExternal
CertificationFCC, CE, RoHS
Placement supportedIndoor & outdoor
Connectivity technologyWireless
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Security algorithmsWPA, WPA2
Alert notification typeE-mail
Sensor typeCMOS
Optical sensor size1/2.9 \
Power consumption200 mA
Power consumption (max)20 W
Storage temperature (T-T)-20 - 50 °C
Operating temperature (T-T)-20 - 60 °C
Storage relative humidity (H-H)0 - 90 %
Operating relative humidity (H-H)20 - 85 %
Mobile operating systems supportedAndroid, iOS
Cables includedLAN (RJ-45)
Audio system2-way
Weight and Dimensions IconWeight and Dimensions
Depth136 mm
Width246 mm
Height202 mm
Weight1500 g
