Foscam SD2X User Manual

11
Back: To stop viewing and listening to the live feed, tap the Back
Resolution: There are three types to identify different streams you have set. If select the FHD Mode, the
clearer video will become, and it will take up more bandwidth; If select the SD Mode, the video will not be
as cleaar as FHD Mode, and it will take up less bandwidth. The HD Model is a value between FHD Mode
and SD Mode.
Bit Rate: Generally speaking, the larger the bit rate is, the clearer video will become. But the bit rate
configuration should combine well with the network bandwidth. When the bandwidth is very narrow, and
bit rate is large, that will lead to video can not play well.
On this screen, you can listen to a live stream, record clips, take a snapshot, activate two-way talk or full
screen.
If you want to catch the smaller details, pinch and drag any image as you do with photos on your
smartphone
IR LED Schedule: On this page, you can enable/disable the IR LED, and set the IR auto switch or you
can schedule it.
Auot: As default, the IR-Cut auto switch is ON, it means that the IR LED will be OFF during 9:00~18:00,
and the IR LED will be ON at the other time.
Day: it means that the IR LED will be OFF all the time.
Night: it means that the IR LED will be ON all the time.
Schedule: You can schedule the time to turn the IR LED OFF/ON.
Back
Speaker / Mute the audio
Resolution
Snapshot
Bit Rate
Camera Setting
Full screen
More Function
Flip
Two-way audio
Cloud Service Subscription
Date
Timeline
Mirro
IR LED Schedule
Pan / Tilt control

Foscam SD2X Specifications

General

Form factor	Dome
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Camera pan control	-
Minimum illumination	0 lx
Optical zoom	18 x
Zoom capability	Yes
Number of lenses	1
Focal length range	5.4 - 97.2 mm
Maximum aperture number	3.6
Minimum aperture number	1.7
LED type	IR
Night vision distance	50 m
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	240p, 480p, 720p, 1080p
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	450 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IP, TCP, UDP, HTTP, HTTPS, DHCP, SMTP, FTP, RTSP, ONVIF
Type	IP security camera
Antenna type	External
Certification	FCC, CE, RoHS
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Security algorithms	WPA, WPA2
Alert notification type	E-mail
Sensor type	CMOS
Optical sensor size	1/2.9 \
Power consumption	200 mA
Power consumption (max)	20 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Mobile operating systems supported	Android, iOS
Cables included	LAN (RJ-45)
Audio system	2-way

Weight and Dimensions

Depth	136 mm
Width	246 mm
Height	202 mm
Weight	1500 g
