Section 2 Multi-Device Window
The firmware inside the camera supports up to maximum of 9 cameras being monitoring at the same
time. You can add other cameras in multi-camera panel.
Section 3 Mode / Stream / WDR / NAA / Mirror / Flip Buttons / Zoom in / out
Mode
1) 50Hz ---------Indoor surveillance (Region: Europe, China)
2) 60Hz ---------Indoor surveillance (Region: USA, Canada)
3) Outdoor Mode------Outdoor surveillance
Stream
The default stream supports multiple modes, For example: HD Mode / 1080P / 25fps / 4M meanings:
Stream type / Resolution / Maximum frame rate / Bit rate. (Different models support different specific
mode. )
1) Stream type no. Identify the stream type.
2) Resolution
The bigger the resolution, the better of the image quality is. If you are accessing the camera via internet
and want to get more fluent video streaming, please select resolution VGA.
3) Maximum frame rate
The maximum frame rate is 30 fps. You should lower frame rate when the bandwidth is limited. Normally,
when the frame rate above 15, you can achieve fluently video. The maximum frame rate for each model
is different.
4) Bit Rate
Generally speaking, the larger the bit rate is, the clearer video will become. But the bit rate configuration
should combine well with the network bandwidth. When the bandwidth is very narrow, and bit rate is
large, that will lead to video cannot play well.
You can reset the stream type on Settings > Video > Video Settings panel.
