CT 293 Cyclotec™
User Manual 6007 0581 / Rev. 3 4:3
4.3 Operation with Large Inlet
When grinding larger quantities of sample or bulky material, the large inlet is a
convenient accessory.
1. Remove the sample inlet.
Note: When taking off the sample inlet. Please use thumb to push
the inlet towards the back of instrument to release the lock pin.
Then remove the sample inlet from the top of instrument. (See
Fig. 3:4)
If you feel it is hard to remove the sample inlet, please use two
hands. While remove the sample inlet, please keep the inlet
horizontal.
2. Install the large inlet according to Fig. 4:3 and fix it by inserting into the correct
position.
Note: When taking off the sample inlet, please remove the
sample tray first. Then use thumb to push the large sample inlet
towards the back of instrument to release lock pins. After that
remove the sample inlet from the top of instrument.
Fig. 4:3
