Fostex LM16 - Technical Specifications; Input and Output Specifications

38
Model LM16 [Specifications]
Others
Frequency response: 20Hz - 20kHz +1dB, -2dB
(44.1/48kHz)
S/N: Line (Trim Min) 103dB (Typical)
Mic (Trim Max) 83dB (Typical)
Dynamic range: 103dB (Trim Min) (Typical)
T.H.D.: Mic (Trim Max) -> ST out: 0.01%
(1kHz, -2dBFS) (Typical)
Line (Trim Min) -> ST out: 0.005%
(1kHz, -2dBFS) (Typical)
Line (Trim Min) -> Phones: 0.1% or less
(1kHz, 50mW, 32Ω)
Inputs/Outputs
Specifications
0dBV = 1.0 Vrms, 0dBu = 0.775 Vrms
Reference level: -20dBfs
Input and Output (Main unit)
[MIC INPUT (1 - 16)]
Connectors: XLR3-31, balanced
(combo)
Nominal input level: -60dBu ~ -12dBu
Input impedance: more than 1.5kΩ
Phantom Power: P48V (1-8ch & 9-16ch
switchable, on/off)
[LINE INPUT (1 - 16)]
Connectors: ø6.3mm TRS phone,
balanced (combo)
Nominal input level: -40dBu ~ +8dBu
Input impedance: more than 10kΩ
[INSERT (1 - 8)]
Connectors: ø6.3mm TRS phone,
(Tip: Output, Ring: Input)
Load impedance: more than 10kΩ
Nominal output level: -10dBV
Input impedance: more than 10kΩ
Nominal input level: -10dBV
[STEREO BUS OUT (L, R)]
Connectors: XLR3-31, balanced
Reference output level:+4dBu
Load impedance: more than 10kΩ
[GROUP BUS OUT (1 - 4)]
Connectors: ø6.3mm TRS phone,
balanced
Reference output level:+4dBu
Load impedance: more than 10kΩ
[AUX SEND (1 - 3)]
Connectors: ø6.3mm phone,
unbalanced
Reference output level:-2dBu
Load impedance: more than 10kΩ
[EFFECT SEND]
Connector: ø6.3mm phone,
unbalanced
Reference output level:-2dBu
Load impedance: more than 10kΩ
[STEREO MIX OUT (L, R)]
Connectors: RCA, unbalanced
Reference output level:-10dBu
Load impedance: more than 10kΩ
[USB (HOST)]
Device: USB2.0 Hi-speed for
storage connection
Connector: A type
[MIDI OUT]
Connector: DIN 5-pin
[TO CONTROL BOX]
Connector: RJ45 (CAT-5, straight)
Input and Output (Control unit)
[PHONES]
Connector: ø6.3mm Stereo Phone
Load impedance: more than 32Ω
[MONITOR OUT (L, R)]
Connector: ø6.3mm Phone,
unbalanced
Reference output level:-12dBV
Load impedance: more than 32Ω
[SUB IN (L, R)]
Connector: RCA, unbalanced
Reference input level: -10dBV
Input impedance: more than 10kΩ
[TO I/O BOX]
Connector: RJ45 (CAT-5, straight)
