Model LM16 [Before using the unit]
Using the supplied power cord, con-
nect the [AC IN] connector on the
rear panel of the main unit and the
AC outlet.
[POWER] switch
AC outlet
Press down the [POWER] switch on
the rear panel of the main unit to
turn on the power.
To turn on or off the LM16 and peripheral devices which are connected to the LM16,
follow the proper procedures described below.
Connecting the power cord
Turning on the power
<Note>: Use only the supplied
power cord.
Preparation of power supply
Procedures of turning on the power after connecting peripheral devices
<Note>: Before turning on or off the LM16 and peripheral devices which are connected
to the LM16, make sure that the channel faders and monitor gain control of the LM16, as
well as the volume control of an monitor amplifier (or powered monitor speaker), are set
to minimum. Otherwise, a loud sound may be produced suddenly that may damage the
speaker or your hearing.
(1) Turn on the devices connected to the [INPUT] connectors to the LM16.
(2) Turn on the LM16.
(3) Turn on the monitor amplifier (or powered monitor speaker).
Procedures of turning off the power after connecting peripheral devices
(1) Turn off the monitor amplifier (or powered monitor speaker).
(2) Turn off the LM16.
(3) Turn off the devices connected to the [INPUT] connectors to the LM16.
