Foundry Networks FES - Chassis Specifications; Physical Dimensions; Environmental Considerations

Foundry Hardware Installation Guide for the FES, FESX, and FWSX
7 - 2 © 2006 Foundry Networks, Inc. June 2006
Chassis Specifications
The following sections present the hardware specifications for the FastIron Stackable devices.
Physical Dimensions
Table 7.2 lists the physical dimensions and weight for the FastIron family of switches.
Environmental Considerations
For optimal performance, operate or store your Foundry device in compliance with the following environmental
conditions.
Operating Environment
Table 7.3 provides the operating environment specifications for the FastIron family of switches.
• Maximum BTUs:
• FES2402, FES4802, FES9604, FES12GCF, and FESX424: 340 BTU/Hr (100 watts) per power supply
Table 7.2: Physical Dimensions and Weight of the FES, FESX, and FWSX
Platform Height Width Depth Weight
FES2402
FES4802
FES12GCF
FESX424
FWSX424
FESX624
2.63 in
6.68 cm
17.5 in
44.45 cm
19.6 in
49.78 cm
• 25 lbs (11.36 kg) fully loaded,
including dual redundant power
supplies
• 17.5 lbs (7.94 kg) empty
FESX448
FWSX448
FESX648
2.63 in
6.68 cm
17.5 in
44.45 cm
19.6 in
49.78 cm
• 25 lbs (11.36 kg) fully loaded,
including dual redundant power
supplies
• 17.5 lbs (7.94 kg) empty
FES9604 4.38 in
11.12 cm
17.5 in
44.45 cm
19.6 in
49.78 cm
• 31 lbs (14.06 kg) fully loaded,
including dual redundant power
supplies
• 23.5 lbs (10.66 kg) empty
FES2402-POE
FES4802-POE
2.63 in
6.68 cm
17.5 in
44.45 cm
19.6 in
49.78 cm
• 29 lbs (13.15 kg) fully loaded,
including dual redundant power
supplies
• 17.5 lbs (7.94 kg) empty
Table 7.3: Operating Environment
Operating Temperature Relative Humidity Operating Altitude
32° – 104° F (0° – 40° C) 5 to 90%, @ 104°F (40° C), non-condensing
or
20 to 90% non-condensing for DC power
supply
0 – 6,600 ft (0 – 2000 meters)
