Product Overview
June 2006 © 2006 Foundry Networks, Inc. 2 - 17
• M-FX – 100BaseFX fiber mini-GBIC
• M-FXB1 or M-FXB2 – 100BaseFX fiber mini-GBIC
• M-LX – 1000BaseLX fiber mini-GBIC
• M-SX – 1000BaseSX fiber mini-GBIC
• M-TX – 1000BaseTX copper mini-GBIC
• M-XR – 1000BaseSX 2 fiber mini-GBIC
• FXB1 or FXB2 – 1000BaseBX fiber mini-GBIC
• M-LHA 1000BaseLHA fiber mini-GBIC
• XG-ZR – 10Gbe ZR XFP fiber transceiver
• XG-ZRD – 10Gbe ZRD XFP fiber transceiver
NOTE: Some older SFP modules (mini-GBICs for Gigabit Ethernet ports) have latching mechanisms which are
larger than the newer parts. These latches could interfere with one another when inserted side by side into a
SuperX module. Avoid using these mini-GBICs side by side in the same module. These older modules are
identified by the number PL-XPL-00-S13-22 or PL-XPL-00-L13-23 above the Serial Number. All newer mini-
GBICs do not have this limitation.
Power Supplies
Each FastIron stackable switch comes with one alternating-current (AC) or direct-current (DC) power supply,
depending on how it was ordered from the factory. All models have two power supply slots, enabling you to install
a second power supply for redundancy. Direct-current (DC) supplies are available for some devices, in which you
can use any combination of AC and DC supplies in the same device. The following table lists the power supplies
that may be installed in a FastIron stackable switch.
The power supplies can be swapped in or out of the device while the device is running. You can remove and insert
a power supply without opening the chassis. If the device contains redundant power supplies, you can remove
one of the supplies without interrupting operation. The remaining supply provides enough power for all the ports.
The following sections provide further details about the power supplies for the FastIron family of switches.
For hardware specifications for the power supplies, see the chapter “Hardware Specifications” on page 7-1.
Device Supported Power Supplies
FES12GCF RPS5-AC and RPS5-DC
FES2402
FES4802
FES9604
FESX424, FESX624,
FESX424HF, and FWSX424
RPS-X424-AC and RPS-X424-DC
FESX424-POE RPS-X424-POE AC and RPSDC-X424-POE
FESX448, FESX648, and
FWSX448
RPS-X448-AC
FES2402-POE RPS8-AC
FES4802-POE
