Hardware Specifications
June 2006 © 2006 Foundry Networks, Inc. 7 - 11
Electrical Specifications
Table 7.12 lists the electrical specifications for the power supplies.
Table 7.12: Power Supply Electrical Specifications
Description
Ranges
RPS5-AC and
RPS-X424-AC
RPS5-DC and
RPS-X424-DC
RPS8-AC, RPS-
X424 POE AC, and
RPS-X448-AC
RPSDC-X424-POE
Operating Specifications
Operating range 85 VAC to 254 VAC
~ 50/60 Hz
85 VAC to 254 VAC
~ 50/60 Hz
40 VDC to 60 VDC
Input Specifications
Input voltage
range
100 - 240 VAC -40 to -60 VDC 100 to 240 VAC -48 to -60 VDC
Input current < 3.5 Amps < 9 Amps <8 Amps <18 Amps
Inrush current < 4.2 Amps peak
maximum
<10 Amps peak
maximum < 150 ms
(0.15 seconds)
< 11.25 Amps peak
maximum
< 26 Amps peak
maximum
Output Specifications
Output power 220 watts of total output power 600 watts of total output power, including
+12VDC @ 10A to the system and -48VDC
@ 10 A for Power over Ethernet
applications
