Chapter 2 Installation Instructions
6
865G/GV/PE7MC User Manual
This motherboard
supports single Pentium
®
4 Processor including Prescott
desktop CPUs in an LGA 775 package. It also supports Hyper-Threading
T
echnology
.
Installation of CPU
Load lever
gLoa
Load stiffener
Load plate
Load cap
Lifted tab
CPU
11
13
