Chapter 4 Driver CD Introduction
46
865G/GV/PE7MC User Manual
Start to install drivers
Click <Install Driver> to enter the driver installation menu (as shown in Figure
1). Click the relevant buttons to install Chipset Software, DirectX 9.0b, VGA
Driver
, USB2.0 Driver
,
Audio Driver and LAN Driver (optional) from this CD.
1
Follow the screen
order to install the
motherboard drivers
51
