Chapter 1 Product Introduction
2
865G/GV/PE7MC User Manual
Main Features
Size
mATX form factor of 9.6 inch x 9.1 inch
Microprocessor
Supports Intel
®
Prescott-T processor in an LGA775 package
Supports FSB at 533MHz/800MHz
Supports Hyper-Threading technology
Chipset
Intel
®
Springdale chipset: Intel
®
865G/GV/PE (North Bridge) + ICH5 (South
Bridge)
System Memory
Two 184-pin DIMM slots
Supports PC 3200/2700/2100 memory
Supports 64/128/256/512 Mb technology up to 2GB
Supports Dual-channel DDR
USB 2.0 Ports
Supports hot plug
Eight USB 2.0 ports (four rear panel ports, two onboard USB headers
providing four extra ports)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 Protocol up to 480 Mbps transmission rate
Onboard Serial ATA
150MBps transfer rate
Supports two S-ATA devices
Onboard 1394 (optional)
Support hot plug
With rate of transmission at 400Mbps
Self-configured addressing
Can connect with 2 independent 1394 units synchronously at most
