3
865G/GV/PE7MC User Manual
Chapter 1 Product Introduction
Onboard LAN (optional)
Supports 10/100/1000 (-K optional) Mbit/sec Ethernet
LAN interface built-in on board
Onboard Audio
AC’97 2.3 Specification Compliant
Supports SPDIF output
Onboard Line-in jack, Microphone-in jack, Line-out jack
Supports 5.1 channels audio (setting via software)
Onboard Graphics (supported on 865G/GV7MC)
Supports integrated VGA display functions (Intel Extreme Graphics)
AGP 8X support (supported on 865G/PE7MC)
AGP 8X (AGP 3.0) is the VGA interface specification that enabled enhanced
graphics performance with high bandwidth speeds up to 2.12 GB/s.
BIOS
Licensed advanced AWARD (Phoenix) BIOS, supports flash ROM, plug-and-
play
Supports IDE, CD-ROM, SCSI HDD and USB device boot up
Green Function
Supports ACPI (Advanced Configuration and Power Interface)
Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off).
Expansion Slots
Three PCI slots
One AGP slot (supported on 865G/PE7MC only)
Advanced Features
PCI 2.3 specification compliant
Supports Windows 98/2000/ME/XP soft-off
Supports PC Health function (capable of monitoring system voltage, CPU,
system temperature, and fan speed)
